- UPB
Porcelain Furnace

UPB
Single curve mode or hyperbolic mode
Low noise tray, programmable speed
The max temperature:1200°C max



UPB Porcelain Furnace
1.Hyperbolic ceramic furnace function, the program can be set to single curve mode or hyperbolic mode,hyperbolic mode provides a complete crystallization process for glass-ceramic crystallization.
2.Voice prompt function.
3.High quality temperature automatic adjustment function, to ensure that the actual temperature error within +/-1 degrees.
4.Precision stepper motor drive, smooth free operation and no jitter.
5.Quartz spiral furnace.
6.Automatic temperature calibration before each baking procedure.
7.Low noise tray, programmable speed.
8.True color touch screen, easy to operate.
9.50 custom programs and built-in programs.
10.Status indication.

The velocity of temperature increasing: 200°C/min max.
The max temperature:1200°C max
The time which can be kept at the max temperature: 2 H
Vacuum level:-90-98kpa
ELECTRIC POWER:
Operation range:100-120V 50/60HZ 230V 50/60HZ
Electric current:14.5ampere@110V 7.0ampere@230V
Power: max 1500w

WXDXH :width 24cm Depth 34cm Height 45cm
Usable measure (firing chamber): 9cm (3.5”) Net weight: 16Kg
Weight include the package:18Kg
