ST89 Dental 3D printer

Digitalized Dental Production

Precise Portable Speedy Stable

Newest Arrival HD 4K LCD Printer for Dentistry

Wider Application

The 3D printer has been improved immensely in printing size, precision and stability, and is now available for various applications like orthodontics & prosthetics in stomatology.

Better Printing Quality

The Z-axis motor system allows the device to have stabler&finer printing performance, as well as service life twice that of common rod motor.

Subpixel Compensation
With the subpixel compensation algorithm, the prints boast smoother surface texture and higher printing accuracy.

Stabler Printing Performance
The optical engine system developed allows the difference in energy distribution to be less than 10%. In this way, more than 90% of the print is promised in its accuracy and success rate is improved by 30%.

.Diagram of energy distribution

Increased Output
ST89 has 97% more print size than traditional DLP printers and can print twenty-one orthodontic dental models at once, twice that of common output.

Easier Operation
When importing oral scanning data(stl.), the software will recognize this file, rotate oral scanning dental models first, keep the teeth straight up or down. Click dental model with right mouse to generate dental base.

Specifications
Print Speed：10-50 mm/H
Build Volume ：192*120*200 mm
Layer Height ：0.025-0.2 mm (Adjustable)
XY Resolution ：0.05 mm
Wavelength：405 nm
Z-axis:Industrial Linear Guide + Ball Screw
Projection Screen:8.9-inch 4K Monochrome Screen
Build Plate:Sandblasting (Increased Adhesion) &
Drilling (Facilitate Drainage)
Vat Capacity:0.5L
Connectivity:USB
Rated Power:320W
Printer Dimension:300*300*536mm
Touch Screen:3.5" Touch Screen
