Features:
Direct low noise thermal printing
Versatile and adaptable
Paper end sensor available
Easy to use and simple to maintain
Support printing graphics and barcode
Specifications:
|
Printing Method
|
Thermal Line
|
|
Resolution
|
8dots/mm, 384dots/line
|
|
Effective Printing Width
|
48mm
|
|
Printing Speed
|
70mm/s
|
|
Character Set
|
ASCII, GB18030(Chinese)
|
|
Print Font
|
ANK: 12 x24 Chinese:24x24
|
|
Self-defined Character
|
YES
|
|
Barcode
|
UPC-A，UPC-E，EAN-13，EAN-8，CODE39，ITF25，CODEBAR，CODE93，CODE128,PDF417,QRCODE,Data Matrix
|
|
Graphic
|
Support bitmap downloading
|
|
Paper End Sensor
|
YES
|
|
Black Mark Location
|
YES
|
|
Overheating Protection
|
YES
|
|
Buzzer
|
YES
|
|
Interface
|
RS-232/Parallel/USB/Bluetooth
|
|
Cash drawer control
|
AC100 ~240V ± 10%(include) DC 12V, 2A
|
|
Power Supply (Adapter)
|
AC100 ~240V ± 10%(include) DC 12V, 2A
|
|
TPH
|
60km
|
|
Paper Type
|
Thermal paper
|
|
Paper Width
|
57.5± 0.5mm
|
|
Paper Thickness
|
0.06 to 0.08mm
|
|
Paper Roll Diameter
|
80mm(Max.)
|
|
Paper Supply Method
|
Drop-in Easy loading
|
|
Paper Cutting Method
|
Manual
|
|
Operating Temp/Humidity
|
0-50°C/10%-80%
|
|
Storage Temp/Humidity
|
-20-60°C / 10%-90%
|
|
Dimension (LxWxH)
|
200 x 140 x120 mm
|
|
Weight
|
898g
|
